Fiberglass Yarns Customized With TEX from 33 to 200TEX

Short Description:

- High tensile strength and excellent durability
- Electrical insulaton
- Resistant to heat, fire and chemicals
-Different linear density with TEX from 33 to 200 TEX
- Can be customized to meet specific application requirements
- KINGDODA manufactures high quality fiberglass yarns at competitive prices.
Acceptance: OEM/ODM, Wholesale, Trade
Payment: T/T, L/C, PayPal
Our factory has been producing fiberglass since 1999. We want to be your best choice and your absolutely reliable business partner.
Any inquiries we are happy to reply, please feel free to send your questions and orders.

Send email to us Phone Whatsapp

Product Detail

Product Tags

Product Description

Continuous Fiberglass yarn has a diameter of 5um-11um. The surface of the yarn is coated with a special sizing that renders good integration of the yarn as well fuzz elimination during unwinding. The yarn has superb weaving performance, and can be desized after the weaving process. It also has a low decomposition temperature and low residue of the final ash content. The resulting fabric after desizing has a white and flat surface. The electronic yarn is the base material for producing electrical insulation articles. It's an optimal structural material for making copper clad laminateds and PCBs. The yarns are also suitable for other weaving and fabric application.

Specification and Physical Properties

Yarn Diameter(um)	Letter Code	Typical Spec
9	G	G37,G67,G75,G150
7	E	E110,E225
6	DE	DE75,DE300
5	D	D450,D900

TECHNICAL DATA
Starch-type yarn
Low fuzz during unwinding, excellent weaving performance, easy desizing, low decomposition temperature, low residue of the fnal ashcontent, white and flat surface of resulting fabric

IPC designation /Typical spec.	Yarn diameter variation %	Linear density variation tex+%	Moisture content %	Combustible matter content %
G37	±10	137.0±3.0	≤0.10	1.10±0.15
G67	±10	74.6±2.5	≤0.10	1.10±0.15
G75	±10	68.9±2.5	≤0.10	1.10±0.15
G150	±10	33.7±4.0	≤0.10	1.05±0.15
E110	±10	44.9±3.0	≤0.10	1.20±0.15
E225	±10	22.5±4.0	≤0.10	1.15±0.20
DE75	±10	68.9±2.5	≤0.10	1.15±0.20
DE300	±10	16.9±5.0	≤0.10	1.30±0.30
D450	±10	11.2±5.5	≤0.10	1.30±0.25
D900	±10	5.6±5.5	≤0.10	1.45±0.30

Packing

Selling Units:Single item
Single package size: 43X38X30 cm
Single gross weight:22.000 kg
Package Type:1kg ,5kg,20kg 25kg per bottle/20kg per set/200kg per bucket

Product Storage and Transportation

Unless otherwise specified, the fiberglass products should be stored in a dry, cool and moisture proof area. Best used within 12 months after production date. They should remain in their original packaging until just prior to use. The products are suitable for delivery by the way of ship, train, or truck.
